Model No.

SP190R083S

SP190R084S

System

CPU

9^th Gen Intel® Coffeelake Refresh i3 9100TE / i5 9500TE / i7 9700TE Processors ( socket LGA1151)

Chipset

Intel Q370 express

Intel C246 express

Memory

2 x 260-pin DDR4 2666MHz SODIMM up to 32 GB

H/W Monitor

H/W Monitor

Watch Dog Timer 256 Level

I/O Ports

HDMI

1

DP

2

USB

8

GLAN

2

4

Line in

1

Line out

1

MIC in

1

Storage

Storage

3 x SATA 3.0  2.5” HDD/SSD

Expansion

Mini PCI-E

1 x Full size , 1 x M Key 2242/2280 , 1 x E key 2230

Power Requirement

Power Requirement

DC in Jack for DC in 19 ~ 24V

Touch Screen

Touch Screen

5 Wires Resistive (one touch)

OS support

OS support

Win 10 (64bit)  /  Linux Kemel 4.x

Display

Size

19" TFT (4:3)

Resolution

1280 x 1024

Colors

16.7M

Luminance

250 cd/m²

Contrast Ratio

1000:1

View Angle (H/V)

170°/160°

Mechanical & Environmental

Operation Temp.

0 ~ 45°C

Storage Humidity

10 ~ 90%, non-condensing

Mounting

VESA mount (100X100mm) & Panel mount & Clip mount

Dimension (WxHxD)

487 x 377 x 95 mm

Weight

8.8 kg

Optional

P/N :305L000023

Intel® i3 9100TE Quad Core, 6M Cache, 3.2GHz

P/N: 305L000015

Intel® i5 9500TE Quad Core, 9M Cache, 3.6GHz

P/N: 305L000022

Intel® i7 9700TE Quad Core, 12M Cache, 3.80GHz

P/N: 2390000003

external antenna ( WIFI )

P/N: 2320000001

Optical Bonding

P/N: 239SP17002

10pcs x Clips

P/N: 3080212009

 1 x RS232/422/485

P/N: 3011100010

Waterproof sponge

Optional HB Panel

SP190R083J

SP190R084J

Resolution

 1280 x 1024

Color

16.7M

Luminance

1000 cd/m²

Contrast Ratio

1000 : 1

Viewing Angle (H/V)

170°/160°

Ordering Information

Standard

SP190R083S04064

Fan 19” panel PC, socket LGA1150, Q370 express, 4GB DDR4 So-DIMM., 64GB SSD,
DC in power adapter

SP190R084S04064

Fan 19” panel PC, socket LGA1150, C246 express, 4GB DDR4 So-DIMM., 64GB SSD,
DC in power adapter

High brightness

SP190R83J04064

Fan 19” panel PC, socket LGA1150, Q370 express, 4GB DDR4 So-DIMM., 64GB SSD,
DC in power adapter, 1000 cd/m²

SP190R84J04064

Fan 19” panel PC, socket LGA1150, C246 express, 4GB DDR4 So-DIMM., 64GB SSD,
DC in power adapter, 1000 cd/m²

**Specifications are subject to change without notice.
