Model No.

QB081WD

QB081WW

System

CPU

Intel® Celeron Apollo Lake E3940 1.6Ghz, up to 1.8Ghz Processor

Memory

1 x 204-pin DDR3L SODIMM up to 8 GB

H/W Monitor

H/W Monitor

Watch Dog Timer 256 Level

I/O Ports

USB 3.0

4

RS232

2

GLAN

2

HDMI

1

DP

1

Storage

Storage

1 x SATA 3.0 2.5” HDD/SSD

Expansion

Mini PCI-E

1 x Full size with SIM socket , 1 x Full size with mSATA

Power Requirement

Power Requirement

2 Pin power terminal block for DC in 12 ~ 24V

OS support

OS support

Win Pro 10  /  Embedded Win 10  /  Win 10 IoT  /  Linux Fedora 25, Ubuntu 16.04

Mechanical & Environmental

Operation Temp.

-40~75°C

Storage Humidity

10 ~ 90%, non-condensing

Mounting

Din Rail

Wall mount

Construction

Aluminum + Steel

Dimension (WxHxD)

167 x 112 x 50 mm

Weight

0.85 kg

Optional

P/N: 3080212003

1 x RS232/422/485

P/N: 3080212003

2 x RS232

P/N: 2390000003

external antenna ( WIFI)

P/N: 308020000C

USB cable

P/N: 3121700001

4GB LTE module

Ordering Information

Standard

DIN Rail installation

QB081WD04064

Fanless wide temperature DIN Rail Box PC Intel E3940, 4GB DDR III L So-DIMM, 64GB SSD, 1 x DC in external power adapter

Wall Mount installation

QB081WW04064

Fanless wide temperature wall mount Box PC Intel E3940, 4GB DDR III L So-DIMM, 64GB SSD, 1 x DC in external power adapter

IIoT gateway

DIN Rail installation

QB081WD14064

Fanless wide temperature DIN Rail Box PC Intel E3940, 4GB DDR III L So-DIMM, mSATA 64GB , 2 x WIFI external antenna, 1 x DC in external power adapter

QB081WD24064

Fanless wide temperature DIN Rail Box PC Intel E3940, 4GB DDR III L So-DIMM, 64GB SSD , 2 x WIFI external antenna, 2 x 4G external antenna,1 x DC in external power adapter

Wall Mount installation

QB081WW14064

Fanless wide temperature wall mount Box PC Intel E3940, 4GB DDR III L So-DIMM, mSATA 64GB, 2 x WIFI external antenna,1 x DC in external power adapter

QB081WW24064

Fanless wide temperature wall mount Box PC Intel E3940, 4GB DDR III L So-DIMM, 64GB SSD, 2 x WIFI external antenna, 2 x 4G external antenna,1 x DC in external power adapter

**Specifications are subject to change without notice.
