Q1: What performance level does the J6412 processor
provide?
A1: The J6412 offers efficient quad-core performance with low power
consumption, making it suitable for industrial automation, HMI, and continuous
operation.
Q2: Does the J6412 support multiple operating systems?
A2: Yes, the platform can support Windows 10, Windows 11, and major Linux
distributions depending on the system configuration.
Q3: Is the J6412 stable for 24/7 industrial use?
A3: Yes, it is designed for long-term embedded applications with excellent
reliability and steady thermal control.
Q4: Can the J6412 handle high-resolution displays?
A4: It supports up to dual displays and modern resolutions commonly used in
industrial HMIs and wide-format screens.
Q5: What type of I/O expansion is available with the J6412 platform?
A5: Depending on system design, it can include COM, USB, LAN, GPIO, and
industrial communication interfaces for automation integration.
Q6: Is hardware acceleration available for graphics or video?
A6: Yes, the J6412 includes integrated graphics for smooth UI rendering and
industrial visualization tasks.
Q7: Does the J6412 provide strong networking capability?
A7: It offers stable connectivity with Gigabit LAN options, suitable for SCADA,
MES, and factory networks.
Q8: Does the J6412 support fanless thermal performance?
A8: Yes, its low TDP makes it ideal for fanless systems, improving durability
in harsh environments.
|
Display for 16:9 Ratio |
|
|||||||
|
Size |
21.5" TFT |
24" TFT |
|
|||||
|
Resolution |
1920 x 1080 |
1920 x 1080 |
|
|||||
|
Colors |
16.7M |
16.7M |
|
|||||
|
Luminance |
250 cd/m2 |
250 cd/m2 |
|
|||||
|
Contrast Ratio |
3000：1 |
1000：1 |
|
|||||
|
View Angle (H/V) |
176°/176° |
170°/160° |
|
|||||
|
Model NO. |
AP215R124S AP215R125S AP215R126S |
AP240R124S AP240R125S AP240R126S |
|
|||||
|
SYSTEM |
|
|||||||
|
CPU |
Intel® Celeron® Processor J6412 , 2.60GHz , TDP 10W |
|
||||||
|
Memory |
2 x DDR4 3200MHz, Dual Channel SO-DIMM, up to 32GB |
|
||||||
|
Storage |
1 x SATA 3.0 |
|
||||||
|
OS Support |
Windows® 11 (64bit) / Windows® 10 (64bit) / Linux (Support by request) |
|
||||||
|
I/O Ports |
⁕ The I/O interface shown may vary depending on the selected motherboard. |
|
||||||
|
M12 RS232 |
2 |
M12 USB 2.0 |
2 |
|
||||
|
M12 GLAN |
2 |
|
|
|
||||
|
Expansion Slot |
|
|||||||
|
M.2 |
1 x M-key 2242/2280 (PCIe Gen.3x2/SATA interface) Support NVME 1 x B-key 3042 (USB3.1/USB2.0 interface) support W/SIM card slot 1 x E-Key 2230 (USB 2.0/PCIe 3.0 x1) |
|
||||||
|
MECHANICAL & ENVIRONMENTAL |
|
|||||||
|
Operation Temp. |
0 ~ 45°C |
|
||||||
|
Storage Humidity |
10 ~ 90%, non-condensing |
|
||||||
|
Form Factor |
|
|||||||
|
Touch Screen |
15"/17"/19"：PCT / 5W ( Single touch ) 15"/17"/19"/21.5"：Projected Capacitive Multi-Touch Panel |
|
||||||
|
Mounting |
VESA mount (100x100mm) & Yoke mount |
|
||||||
|
Power Supply |
3 Pin Power Terminal Block for DC-in 12~24V |
|
||||||
|
Optional |
|
|||||||
|
Panel Type |
High Brightness LCD Panel: Available in various sizes and brightness specifications. Please inquire for available options and custom configurations |
|
||||||
|
WIFI Optional |
External Antenna (Wi-Fi): Supports M.2 Wi-Fi module with external antenna connection for enhanced signal performance |
|
||||||
|
Power adaptor |
Full IP67 Waterproof Power adaptor : Specifications may vary by country ( 75W / 100 ~ 305V AC input / 12V DC output) / (75W / 100 ~ 305V AC input / 24V DC output) |
|
||||||
