Model No. |
QB140/141/142/143SD |
QB140/141/142/143SW |
|
System |
||
|
CPU |
8th Gen Intel® Core™ Celeron 4305UE/ i3 8145UE / i5 8365UE / i7 8665UE Processors CPU (On Board) |
|
|
Memory |
2 x 260-pin DDR4 2400MHz SODIMM up to 32 GB |
|
|
H/W Monitor |
||
|
H/W Monitor |
Watch Dog Timer 256 Level |
|
|
TPM |
||
|
Controller |
Infineon SLB9670TT2.0 |
|
|
Front Panel |
||
|
Power LED |
1 |
|
|
HDD LED |
1 |
|
|
I/O Ports |
||
|
USB 3.2 |
4 |
|
|
USB 2.0 |
2 |
|
|
RS232/RS422/RS485 |
4 |
|
|
GLAN |
4 |
|
|
GLAN |
2 x ( Isolated RJ45 ports) |
|
|
HDMI |
1 |
|
|
DP |
1 |
|
|
GPIO |
16 bits ( 8 x GPI , 8 x GPO), 5V , 2 x D- SUB connectors |
|
|
Storage |
||
|
Storage |
2 x SATA 3.0 |
|
|
Expansion |
|||||
|
M.2 |
1 x M.2 M Key(SATA) 2242 1 x M.2 E Key ( PCI e x 1 USB 2.0, w/CNVi ) 2230 |
||||
|
Power Requirement |
|||||
|
Power Requirement |
2 Pin power terminal block for DC in 12 ~ 24V ( OCP & OVP ) |
||||
|
OS support |
|||||
|
OS support |
Win Pro 10 / Win 10 IoT LTSC/SAC (64 bit RS5) / Linux fedora 29 Ubuntu 18.04 |
||||
|
Mechanical & Environmental |
|||||
|
Operation Temp. |
0 ~50°C |
||||
|
Storage Humidity |
10 ~ 90%, non-condensing |
||||
|
Mounting |
DIN Rail |
Wall mount |
|||
|
Construction |
Aluminum heatsink + Steel chassis |
||||
|
Dimension (WxDHxH) |
185 x 110 x 76 mm |
||||
|
Weight |
1.3Kg |
||||
|
Ordering Information |
|
||||
|
DIN Rail installation |
|
||||
|
QB140SD04128 |
Fanless DIN Rail Box PC, Intel Celeron 4305UE,4GB DDR 4 So-DIMM, M.2 128GB SSD, DC in external power adapter |
|
|||
|
QB141SD04128 |
Fanless DIN Rail Box PC, Intel i3 8145UE, 4GB DDR 4 So-DIMM,M.2 128GB SSD, DC in external power adapter |
|
|||
|
QB142SD04128 |
Fanless DIN Rail Box PC, Intel i5 8365UE, 4GB DDR 4 So-DIMM, M.2 128GB SSD, DC in external power adapter |
|
|||
|
QB143SD04128 |
Fanless DIN Rail Box PC, Intel i7 8665UE, 4GB DDR 4 So-DIMM, M.2 128GB SSD, DC in external power adapter |
|
|||
|
Wall Mount installation |
|
||||
|
QB140SW04128 |
Fanless wall mount Box PC, Intel Celeron 4305UE, 4GB DDR 4 So-DIMM, M.2 128GB SSD, DC in external power adapter |
|
|||
|
QB141SW04128 |
Fanless wall mount Box PC, Intel i3 8145UE, 4GB DDR 4 So-DIMM, M.2 128GB SSD, DC in external power adapter |
|
|||
|
CB142SW04128 |
Fanless wall mount Box PC, Intel i5 i5 8365UE, 4GB DDR 4 So-DIMM, M.2 128GB SSD, DC in external power adapter |
|
|||
|
CB143SW04128 |
Fanless wall mount Box PC, Intel i7 8665UE, 4GB DDR 4 So-DIMM, M.2 128GB SSD, DC in external power adapter |
|
|||
