Model No.

QB081WD

QB081WW

System

CPU

Intel® Celeron Apollo Lake E3940 1.6Ghz, up to 1.8Ghz Processor

Memory

1 x 204-pin DDR3L SODIMM up to 8 GB

H/W Monitor

H/W Monitor

Watch Dog Timer 256 Level

I/O Ports

USB 3.0

4

RS485

2 x (DB-9 2.5kV isolation)

RS422

2 x (DB-9 2.5kV isolation)

GLAN

2

HDMI

1

DP

1

Storage

Storage

1 x SATA 3.0 2.5” HDD/SSD

Expansion

Mini PCI-E

1 x Full size with mSATA

Power Requirement

Power Requirement

2 Pin power terminal block for DC in 12 ~ 24V

OS support

OS support

Win Pro 10 / Win 10 IoT / Linux Fedora 25, Ubuntu 16.04

Mechanical & Environmental

Operation Temp.

-40~70°C

Storage Humidity

10 ~ 90%, non-condensing

Mounting

Din Rail

Wall mount

Construction

Aluminum + Steel

Dimension (WxHxD)

167 x 112 x 50 mm

Weight

0.85 kg

Ordering Information

QB081WD04128

Fanless wide temperature DIN Rail Box PC Intel E3940, 4GB DDR III L So-DIMM, TLC mSATA128GB SSD, 1 x DC in external power adapter

QB081WW04128

Fanless wide temperature wall mount Box PC Intel E3940, 4GB DDR III L So-DIMM, TLC mSATA128GB SSD, 1 x DC in external power adapter
