Model No. |
WM190RW03 |
WM190RW04 |
|
Display |
|||
Size |
19" TFT (4:3) |
||
Resolution |
1280 x 1024 |
||
Colors |
16.7M |
||
Luminance |
250 cd/m2 |
||
Contrast Ratio |
1000:1 |
||
View Angle (H/V) |
170°/160° |
||
High Brightness (Optional) |
|||
Resolution |
1280 x 1024 |
||
Color |
16.7M |
||
Luminance |
1000 cd/m2 |
||
Contrast Ratio |
1000 : 1 |
||
Viewing Angle (H/V) |
170°/160° |
||
I/O Ports |
|||
VGA |
V |
V |
|
HDMI |
|
V |
|
USB (for touch screen) |
V |
V |
|
Power Requirement |
|||
Power Requirement |
DC in 12V ( 60W ) |
||
Touch Screen |
|||
Touch Screen |
5 Wires Resistive (one touch) |
||
OS support |
|||
OS support |
Win Pro 10 / Embedded Win 7, 8, 10 |
||
Mechanical & Environmental |
|||
Operation Temp. |
-20~60°C |
||
Storage Humidity |
10 ~ 90%, non-condensing |
||
Mounting |
VESA mount (100X100mm) & Yoke mount |
||
Dimension (WxHxD) |
455 x 367 x 67 mm |
||
Weight |
8.8 kg |
||
Optional |
|||
P/N: 302A190091 |
1600 cd/m2 19” LCD panel 1280 x 1024 |
||
P/N: 2351206003 |
Full IP65 Waterproof Power adaptor with European power cord |
||
P/N: 2352406011 |
Full IP65 Waterproof Power adaptor with European power cord |
||
P/N: 2351206004 |
Full IP65 Waterproof Power adaptor with US power cord |
||
P/N: 2352406012 |
Full IP65 Waterproof Power adaptor with US power cord |
||
P/N: 2320000001 |
Optical Bonding |
||
P/N: 309M106004 |
DC in 9V ~ 36V |
||
P/N: 3120600002 |
RS232 touch screen |
||
Ordering Information |
|||
Standard |
|||
WM190RW03 |
19” wide temperature full IP65 display, 5 wires resistive, 1 x VGA, 1 x USB, 1 x 1.8m VGA cable, 1 x 1.8m USB cable, 1 x DC in external power adapter |
||
WM190RW04 |
19” wide temperature full IP65 display, 5 wires resistive, 1 x VGA, 1 x HDMI, 1 x USB, 1 x 1.8m VGA cable, 1 x 2m HDMI cable, 1 x 1.8m USB cable, 1 x DC in external power adapter |
||
High Brightness |
|||
WM190RK03 |
19” wide temperature full IP65 Display, 5 wires resistive, 1 x VGA, 1 x USB, 1 x 1.8M VGA cable, 1 x 1.8M USB cable, 1 x DC in external power adapter, 1000 cd/m2 |
||
WM190RK04 |
19” wide temperature full IP65 Display, 5 wires resistive, 1 x VGA, 1 x HDMI, 1 x USB, 1 x 1.8M VGA cable, 1 x 2M HDMI cable, 1 x 1.8M USB cable, 1 x DC in external power adapter, 1000 cd/m2 |
||
**Specifications are subject to change without notice. |
