SYSTEM

CPU

Intel® Celeron® Processor J6412, QC, 10W

Memory

2 x SO-DIMMs DDR4 3200 MHz Up to 32 GB

Storage

1 x SATA 3.0

OS Support

Windows 10 IoT Enterprise 2021 LTSC (64-bit, 21H2)

Linux (Support by request)

TPM

Infineon SLB9672VU 2.0

RS232/422/485

2 (COM1、COM2) Optional

RS232

4 (COM3~6) Optional

HDMI

1

DP

1

GLAN

2

USB 2.0

1

USB3.2 Gen2

3

AUDIO

1

Expansion Slot

M.2

1 x M key 2242 ( SATA )

1 x B key 2242 / 3042 ( PCIe x1, USB 3.2 Gen 1 x 1, USB 2.0 w / NANO SIM-Holder )

1 x E key 2230 ( PCIe x1, USB 2.0 ) WiFi optional

MECHANICAL & ENVIRONMENTAL

Operation Temp.

0 ~ 45°C

Storage Humidity

10 ~ 90%, non-condensing

Form Factor

Mounting

Wall mount

Power Supply

3 Pin Power Terminal Block for DC-in 12V/19V/24V
