SYSTEM

CPU

Intel® Mobile 13th Core™  i7-1365URE/ i5-1345URE/ i3-1315URE , 28W

Memory

Single-channel DDR5 5200 MHz Up to 32 GB

Storage

1 x SATA 3.0

OS Support

Windows 10 IoT Enterprise 2021 LTSC (64-bit, 21H2)

Windows 11 IoT Enterprise (64-bit, 23H2, Pre-scan)

Linux (Support by request)

I/O Ports

⁕ The I/O interface shown may vary depending on the selected motherboard.

M12 USB2.0

2

M12 GLAN

2

M12 RS232

2

M16 HDMI

1

Expansion Slot

M.2

1 x M.2 M key (PCIe Gen4 x4 NVMe), 2280

1 x M.2 B key (PCIe x1, USB 2.0, w/NANO SIM-Holder), 2242/3042

1 x M.2 E key (PCIe x1, USB 2.0, w/CNVi), 2230

MECHANICAL & ENVIRONMENTAL

CPU Operation Temp.

-40 ~ 85°C

SSD Operating Temp.

0℃~70℃ , PHISON,SSBP128GKB5C0-S11,2.5",TLC128G

Memory Operating Temp.

0℃~70℃ , Apacer,D22.35491H.001,DDR5 SO-DIMM 5600-46 1024x16 8GB

Storage Humidity

10 ~ 90%, non-condensing

Form Factor

Mounting

Wall Mount Installation

Power Supply

M12 IP67 waterproof power supply for DC-in 12 or 24V
