Q1 : What temperature range does the AP Series with CF17
Wide Temp support?
A1 : It supports –40°C to +70°C, ensuring reliable performance in cold
rooms, outdoor sites, and high-heat industrial environments.
Q2 : Are all models designed with full IP69K stainless protection?
A2 : Yes. Every size in the AP Series features a full IP69K stainless
enclosure for washdown and hygiene-critical applications.
Q3 : Do the connectors provide complete waterproof sealing?
A3 : Yes. All models use M12 waterproof connectors for maximum ingress
protection and long-term industrial durability.
Q4 : What touch options are available for the AP Series?
A4 : Both True Flat projected capacitive touch and 5-wire resistive
touch are available depending on glove usability and application needs.
Q5 : Is the AP Series fully fanless?
A5 : Yes. The fanless design prevents contamination, supports silent
operation, and enhances reliability in harsh environments.
Q6 : What mounting methods are supported?
A6 : All models support Yoke Mount and VESA Mount for flexible
installation in machinery, production lines, and workstations.
Q7 : Which industries typically adopt the AP Series with
wide-temperature support?
A7 : Food and beverage, cold storage, chemical processing, outdoor
automation, and environments requiring extreme temperature resistance.
Q8 : Does the AP Series offer high-performance computing?
A8 : Yes. With Intel® i3/i5/i7, it supports demanding workloads such as
automation control, data processing, visualization, and edge computing.
|
Display for 3:4 Ratio |
|
||||||||||
|
Size |
15" TFT |
17" TFT |
19" TFT |
|
|||||||
|
Resolution |
1024 x 768 |
1280 x 1024 |
1280 x 1024 |
|
|||||||
|
Colors |
16.7M |
16.7M |
16.7M |
|
|||||||
|
Luminance |
300 cd/m2 |
350 cd/m2 |
250 cd/m2 |
|
|||||||
|
Contrast Ratio |
2500:1 |
1000:1 |
1000：1 |
|
|||||||
|
View Angle (H/V) |
176°/176° |
170°/160° |
170°/160° |
|
|||||||
|
Model NO. |
AP150R124S AP150R125S AP150R126S |
AP170R124S AP170R125S AP170R126S |
AP190R124S AP190R125S AP190R126S |
|
|||||||
|
SYSTEM |
|
||||||||||
|
CPU |
Intel® Mobile 13th Core™ i7-1365URE(124)/ i5-1345URE(125)/ i3-1315URE(126) , 28W |
|
|||||||||
|
Memory |
Single-channel DDR5 5200 MHz Up to 32 GB |
|
|||||||||
|
Storage |
1 x SATA 3.0 |
|
|||||||||
|
OS Support |
Windows 10 IoT Enterprise 2021 LTSC (64-bit, 21H2) Windows 11 IoT Enterprise (64-bit, 23H2, Pre-scan) Linux (Support by request) |
|
|||||||||
|
I/O Ports |
⁕ The I/O interface shown may vary depending on the selected motherboard. |
|
|||||||||
|
M12 RS232 |
2 |
M12 USB 2.0 |
2 |
|
|||||||
|
M12 GLAN |
2 |
|
|
|
|||||||
|
Expansion Slot |
|
||||||||||
|
M.2 |
1 x M.2 M key (PCIe Gen4 x4 NVMe), 2280 1 x M.2 B key (PCIe x1, USB 2.0, w/NANO SIM-Holder), 2242/3042 1 x M.2 E key (PCIe x1, USB 2.0, w/CNVi), 2230 |
|
|||||||||
|
MECHANICAL & ENVIRONMENTAL |
|
||||||||||
|
Operation Temp. |
-40 ~ 70°C |
|
|||||||||
|
Storage Humidity |
10 ~ 90%, non-condensing |
|
|||||||||
|
Form Factor |
|
||||||||||
|
Touch Screen |
True flat PCT / 5 wires resistive |
|
|||||||||
|
Mounting |
Yoke Mount / VESA Mount |
|
|||||||||
|
Power Supply |
Full IP67 Waterproof Power Adapter: 12V/24V default; 9–36V input supported. Customization by customer. |
|
|||||||||
|
Optional |
|
||||||||||
|
Panel Type |
High Brightness LCD Panel: Available in various sizes and brightness specifications. Please inquire for available options and custom configurations |
|
|||||||||
|
WIFI Optional |
External Antenna (Wi-Fi): Supports M.2 Wi-Fi module with external antenna connection for enhanced signal performance |
|
|||||||||
|
Power adaptor |
Full IP67 Waterproof Power adaptor : Specifications may vary by country ( 150W / 100 ~ 305V AC input / 12V DC output) / (150W / 100 ~ 305V AC input / 24V DC output) |
|
|||||||||
