Q1: What makes the CF17 3.5"" SBC suitable for industrial use?
A1: Its fanless rugged design, wide voltage input (12V), and IP65 front bezel make it ideal for harsh environments.
Q2: Which CPU options are available?
A2: The CF17 supports 13th Gen Intel® Core™ i7, i5, and i3 processors, delivering scalable performance for various workloads.
Q3: Does it support high-performance memory?
A3: Yes, it supports DDR5 memory up to 16GB, ensuring fast data processing and smooth multitasking.
Q4: What display sizes can be paired with CF17?
A4: Compatible with multiple display sizes including 12"", 15"", 15.3"", 17"", 17.3"", 18.5"", 19"", 21.5"", and 24".
If you want smaller, like 7", or bigger, like 27", please mail to our sales team. Mail add : sales@kingdy.com.tw
Q5: What industries benefit most from CF17?
A5: Common applications include smart manufacturing, automation, kiosk systems, AIoT devices, and industrial control.
|
Display for 3:4 Ratio |
|
||||||||
|
Size |
15" TFT |
17" TFT |
19" TFT |
|
|||||
|
Resolution |
1024 x 768 |
1280 x 1024 |
1280 x 1024 |
|
|||||
|
Colors |
16.7M |
16.7M |
16.7M |
|
|||||
|
Luminance |
300 cd/m2 |
350 cd/m2 |
250 cd/m2 |
|
|||||
|
Contrast Ratio |
2500:1 |
1000:1 |
1000：1 |
|
|||||
|
View Angle (H/V) |
176°/176° |
170°/160° |
170°/160° |
|
|||||
|
Model NO. |
SP150R120S SP150R121S SP150R122S SP150R123S |
SP170R120S SP170R121S SP170R122S SP170R123S |
SP190R120S SP190R121S SP190R122S SP190R123S |
|
|||||
|
SYSTEM |
|
||||||||
|
CPU |
Intel® Mobile 13th Core™ i7-1365UE(120)/ i5-1345UE(121)/ i5-1335UE(122)/ i3-1315UE(123) , 28W |
|
|||||||
|
Memory |
Single-channel DDR5 5200 MHz Up to 32 GB |
|
|||||||
|
Storage |
1 x SATA 3.0 |
|
|||||||
|
OS Support |
Windows 10 IoT Enterprise 2021 LTSC (64-bit, 21H2) Windows 11 IoT Enterprise (64-bit, 23H2, Pre-scan) Linux (Support by request) |
|
|||||||
|
I/O Ports |
⁕ The I/O interface shown may vary depending on the selected motherboard. |
|
|||||||
|
RS232 |
2 |
GLAN |
4 |
|
|||||
|
HDMI |
4 |
USB 3.2 Gen 2 |
4 |
|
|||||
|
Expansion Slot |
|
||||||||
|
M.2 |
1 x M.2 M key (PCIe Gen4 x4 NVMe), 2280 1 x M.2 B key (PCIe x1, USB 2.0, w/NANO SIM-Holder), 2242/3042 1 x M.2 E key (PCIe x1, USB 2.0, w/CNVi), 2230 |
|
|||||||
|
MECHANICAL & ENVIRONMENTAL |
|
||||||||
|
Operation Temp. |
0 ~ 45°C |
|
|||||||
|
Storage Humidity |
10 ~ 90%, non-condensing |
|
|||||||
|
Form Factor |
|
||||||||
|
Touch Screen |
5 Wires Resistive ( Single touch ) |
|
|||||||
|
Mounting |
VESA mount ( 75 X 75 mm) / ( 100 X 100 mm) & Panel mount & Clip mount |
|
|||||||
|
Power Supply |
3 Pin Power Terminal Block for DC-in 12~24V |
|
|||||||
