Q1: What processor options are available for this industrial panel PC?
A1: It supports 7th Gen Intel® Core™ i3, i5, and i7 processors, offering scalable performance for entry-level to high-end industrial applications.
Q2: What are the key rugged features of this panel PC?
A2: Fanless design, IP65-rated silver aluminum front bezel, and wide voltage input (12V~24V) ensure durability in harsh environments.
Q3: What display sizes are offered?
A3: Available from 12"" up to 24"", including 15.3"", 17.3"", and 21.5"" wide-screen models.
Q4: What industries can use this panel PC?
A4: Factory automation, industrial control, smart manufacturing, kiosks, monitoring systems, and data visualization.
Q5: Does it support multiple mounting methods?
A5: Yes, it supports VESA mount, Panel mount, and Clip mount for flexible installation.
Q6: What connectivity is included?
A6: 2 x USB, 2 x RS232, 2 x GLAN, 1 x HDMI, 1 x VGA, and 1 x DP for versatile integration.
|
Display for 3:4 Ratio |
|
||||||
|
Size |
12.1" TFT |
|
|||||
|
Resolution |
1024 x 768 |
|
|||||
|
Colors |
16.7M |
|
|||||
|
Luminance |
350 cd/m2 |
|
|||||
|
Contrast Ratio |
800:1 |
|
|||||
|
View Angle (H/V) |
160°/160° |
|
|||||
|
Model NO. |
SP121R075S SP121R076S SP121R077S |
|
|||||
|
SYSTEM |
|
||||||
|
CPU |
7th Gen Intel® Core™ i3 7100U (075)/ i5 7300U (076)/ i7 7600U (077) CPU (On Board) |
|
|||||
|
Memory |
1 x 260-pin DDR4 2133MHz SODIMM up to 16 GB |
|
|||||
|
Storage |
1 x SATA 3.0 2.5”HDD/SSD |
|
|||||
|
OS Support |
Windows 10 Pro / Windows 10 IoT / Linux |
|
|||||
|
I/O Ports |
⁕ The I/O interface shown may vary depending on the selected motherboard. |
|
|||||
|
RS232 |
2 |
USB 3.2 Gen 1 |
4 |
|
|||
|
HDMI |
1 |
GLAN |
2 |
|
|||
|
DP |
1 |
|
|||||
|
Expansion Slot |
|
||||||
|
M.2 |
2 x Full size Mini PCI-E ( one w / NANO SIM-Holder & one w / mSATA) / WiFi optional |
|
|||||
|
MECHANICAL & ENVIRONMENTAL |
|
||||||
|
Operation Temp. |
0 ~ 45°C |
|
|||||
|
Storage Humidity |
10 ~ 90%, non-condensing |
|
|||||
|
Form Factor |
|
||||||
|
Touch Screen |
5 Wires Resistive ( Single touch ) |
|
|||||
|
Mounting |
VESA mount (75 X 75mm / 100x100mm) & Panel mount & Clip mount |
|
|||||
|
Power Supply |
3 Pin power terminal block for DC in 12V ~ 24V |
|
|||||
